RUIJIE industrial robust iron hammer crusher is designed for fine crushing of medium-hard and brittle materials across diverse industrial applications. It offers versatile performance with adjustable crushing fineness, delivering high production efficiency, low energy consumption, safe operation, and convenient maintenance.
Ruijie industrial iron Hammer Crusher is a critical piece of primary crushing equipment across a wide range of industries, including pharmaceuticals, feed production, food processing, coatings, and chemical manufacturing.
It eliminates the need for a preliminary jaw crusher stage, enabling one-step crushing of both large and small materials to achieve desired fineness in a single pass.
This versatile crusher offers adjustable crushing precision, high production efficiency, low energy consumption, safe operation, and easy maintenance. These advantages have made it a preferred choice for businesses seeking to optimize their material processing workflows.
Principle
The Ruijie industrial iron hammer crusher utilizes high-speed impact as its core crushing mechanism.
When material enters the hammer mill, it is immediately subjected to the impact of rapidly rotating hammers, initiating primary crushing. The fragmented material gains kinetic energy from the hammers and is propelled against the machine’s internal baffles and grate bars.
As materials collide with each other and the internal components, they undergo repeated secondary crushing. Particles smaller than the grate bar gaps are discharged immediately, while larger pieces remain in the crushing chamber. These larger materials are re-impacted, ground, and squeezed against the grate bars until they are reduced to the desired particle size and pass through the gaps, ensuring a uniformly crushed end product.
Feature
Advanced One-Step Processing – Utilizes state-of-the-art production technology for one-time feeding and molding, delivering high efficiency, energy savings, and eco-friendly performance.
Adjustable Particle Size – Output can be flexibly adjusted to coarse, medium, fine, or custom specifications to meet diverse production requirements.
Robust Impact Resistance – Multi-angle, multi-edge design ensures exceptional compressive strength and durability in heavy-duty crushing.
High-Efficiency Crushing – Handles both large and small materials in a single pass, with high output, low power consumption, and reduced labor/material costs, lowering overall processing expenses.
Low Maintenance Design – Minimal wear and tear, combined with easy access for servicing, ensures long-term reliability and reduced downtime.
Uniform Product Quality – Produces consistently sized particles for stable downstream processing and end-product quality.
Technical Parameter
Model
Feed Inlet (mm)
Power (kw)
Rotor Rotation Speed(r/min)
Processing Capacity (t/h)
Dimensions （L*W*H）(mm)
Weight (kg）
PC-DT1000
910x366
80-120
960-1200
4-6
1500x1930x1320
4206
Applicable to Various Scenarios
The Model PC-DT1000 is a hammer iron crusher with processing capacity of 4~6 ton per hour. It is equipped with high rotor rotation speed, high efficiency for iron crushing.
It is engineered to deliver reliable performance across a wide range of heavy-duty industrial applications, making it a versatile solution for diverse material processing needs:
Mining Industry: Efficiently crushes hard rock and ore to support mineral extraction and processing workflows.
Urban Architecture: Processes construction aggregates and recycled building materials for infrastructure and commercial projects.
Heat-engine Plant: Reduces coal and slag into uniform particles to optimize combustion efficiency and energy production.
Sand Making Plant: Produces high-quality, graded sand for concrete, asphalt, and other construction materials.
Its robust design and adaptability ensure consistent performance in harsh operating environments, meeting the demands of modern industrial production.
